The Dock Flex Test Board is a professional mobile phone diagnostic tool designed to test U2 IC, battery performance, charging ports, and USB charging circuits on compatible iPhone and Android smartphones. It allows technicians to perform essential charging-system checks without disassembling the phone, helping save valuable repair time and reducing unnecessary component removal.

Simply connect the test board directly to the phone’s charging/tail plug and use a multimeter in diode mode to compare measurements. The board is particularly useful for identifying whether a charging problem originates from the charging port, battery, U2/charging IC circuit, or related lines.

Key Features

• No Phone Disassembly Required: Perform charging and battery-related tests without opening the smartphone.
• U2 IC Testing: Helps technicians diagnose the U2 IC and associated charging circuitry.
• Battery Testing: Check battery-related lines and compare measured values to identify abnormalities.
• USB Charging Port Testing: Designed to test charging-port performance and related circuits.
• Direct Tail Plug Connection: Connect the board directly to the phone’s charging connector for convenient testing.
• iPhone & Android Compatibility: Available for compatible Lightning, Micro-USB, and Type-C charging interfaces depending on the selected version.
• Multimeter Compatible: Measurements can be performed using diode-mode testing with a standard multimeter.
• Fast Fault Diagnosis: Makes it easier to distinguish between charging-port, battery, and motherboard-side problems.
• Compact Repair Tool: Small and convenient for use at professional mobile repair workstations.
• Ideal for Technicians: Suitable for mobile phone repair shops, motherboard repair technicians, and electronics troubleshooting.

Technical Specifications
