RF4 RF6565Pro 6.5-65X Synchronous Zoom Trinocular Stereo Microscope with Aluminum Alloy Base

Description

RF4 RF6565Pro 6.5-65X Synchronous Zoom Trinocular Stereo Microscope with Aluminum Alloy Base.

Features :

• High quality materials ensure the durability and stability of products
• Whether the objective lens can be protected to effectively prevent smoke generated during welding from entering the objective lens
• The high transparency of the lens does not affect observation
• Beautiful process, strong lens applicability

Features: Clear stereo sound, wide field of vision. Pupils are 6.5 to 65 mm apart.

Wide Field of View Eyepiece WF10X/23mm 10X wide-angle eyepiece with a field of view of 23mm, flat high Angle design, better for search and observation. Ergonomic design, shift handwheel horizontal (axial) two-way setting, high repetition accuracy.

Stereo microscopes are simple to operate and widely used.

• Stereo microscope is simple to operate.
• It is widely used. Zoology, biology, botany, entomology, Histology, mineralogy, archaeology, geology and dermatology.
• In the textile industry, it is used for the inspection of raw materials and cotton-wool fabrics.
• Used in the electronics industry as a triode welding, mobile phone electronic maintenance, watch maintenance and inspection and other operating tools.
• In biological anatomy, used in regional anatomy.
• In the manufacture of precision parts, it is used to observe the working process of machine tool equipment, check and assemble precision parts.
• Check the surface quality of lenses, prisms or other transparent substances with precision ruler.
• Cultural relics, books, coins, painting and calligraphy, inspection are widely used in textile products, chemical products, plastic products, electronic manufacturing, machinery manufacturing, pharmaceutical manufacturing, food processing, printing industry, colleges and universities, archaeological research and many other fields.

Specification:

• Magnification: Continuous zoom 6.5X to 65X
• Head: 45-degree inclined 360-degree swiveling trinocular
• Eyepiece: WF10X/22MM
• Objective: 0.65-6.5X
• Camera connector: 0.5X
• Monitor and eyepiece: Synchronous zoom
• Accessories: 144 adjustable led lights & dust proof Lens

Support Parameters:

• Column aperture: Φ32mm
• Lens aperture: Φ76mm
• Center distance: 155mm
• Lifting range: 50mm

Wide-angle Eyepieces 10X/22:

• Magnification: 10X
• Wide field of view 22mm
• Matching size: 30mm
• Applicable models: Stereoscopic, fixed, and continuous magnification microscopes

0.5X CTV Lens :

• The material is all metal, the black part is aluminum alloy, and the silver part is a copper chrome-plated bayonet
• The adapter ring can use LCD to focus, this kind of focus method is manual focus
• The adapter has a transparent mirror inside, which can help the microscope display and the other display achieve synchronous zooming

144 LED Ring Light :

• Input: AC 100~240V 50/60Hz
• Output: DC 12V, Max 700mA
• Light color: White
• Number of lights: 144 LEDs
• Inside diameter: 60mm

1. 144 LED ring lights are specially designed for stereo microscopes and are the best companion for various microscopes and cameras.
2. It provides the best amount of light for a microscope or camera when additional light sources are needed or when light is insufficient.
3. Inspection and quality control is no longer a matter of looking at surface defects, and the associated visibility issues are addressed.
4. Protect users and equipment from mild to severe static electricity
5. Brightness adjustable, flexible to adapt to any work and consistent lighting object lighting
6. Adjustable screws for fixing the lamp on the microscope.
7. Provide cool, uniform, no glare, no focus shadow lighting
8. Low temperature, even if used for a long time, can also maximize the user’s comfort and operability.

Package includes:

• 1 x Microscope
• 1 x Aluminum Alloy Plate
• 1 x 144 LED Light
• 1 x Dust proof Lens
• 1 x 0.5X CTV Lens
• 1 x Eye Rubber Guard
